HowTo create a custom Redmine theme¶

Redmine offers basic support for themes. Themes can override stylesheets (application.css) and add some custom javascript.

NOTE: From Redmine 6.0, the location for themes changed from public/themes to themes. If you are creating a theme for a version prior to 6.0, please read themes as public/themes in the following instructions.

Creating a new theme¶

Create a directory in /themes. The directory name will be used as the theme name.

Example:

themes/my_theme

Create your custom application.css and save it in a subdirectory named stylesheets:

themes/my_theme/stylesheets/application.css

Here is an example of a custom stylesheet that only override a few settings:

/* load the default Redmine stylesheet */
@import url(../../../stylesheets/application.css);

/* add a logo in the header */
#header {
    background: #507AAA url(../images/logo.png) no-repeat 2px;
    padding-left: 86px;
}

/* move the project menu to the right */
#main-menu {
    left: auto;
    right: 0px;
}

This example assume you have an image located at my_theme/images/logo.png.

You can download this sample theme as a starting point for your own theme. Extract it in the /themes directory.

NOTE: From Redmine 6.0, The code @import url(../../../stylesheets/application.css) shown in the example above is automatically converted to @import url(“/assets/application-29b28b2c.css”); when Redmine starts. The combination of numbers and letters at the end of the filename is a hash value calculated from the file's contents. Since the filename changes whenever the content is modified, issues like display corruption caused by browsers using outdated cached versions are avoided.

Adding custom JavaScript¶

Simply put your JavaScript in javascripts/theme.js and it will automatically be loaded on each page.

NOTE: From Redmine 6.0, When specifying image paths in JavaScript, use the RAILS_ASSET_URL pseudo-method as shown in the example below. For more detailed conversion specifications, refer to README of propshaft

Source:

export default class extends Controller {
  init() {
    this.img = RAILS_ASSET_URL("/icons/trash.svg")
  }
}

Transformed:

export default class extends Controller {
  init() {
    this.img = "/assets/icons/trash-54g9cbef.svg"
  }
}

Setting a Favicon¶

Put your favicon in favicon directory and it will automatically be loaded instead of default one on each page. The name of the favicon file can be anything.

Applying the theme¶

Go to "Administration -> Settings" and select your newly created theme in the "Theme" drop-down list. Save your settings.
Redmine should now be displayed using your custom theme.

Directory structure of themes¶

A theme consists of the following files:

• favicon/<favicon file> (optional): favicon for the theme
• javascripts/theme.js (optional): custom JavaScript for the theme
• stylesheets/application.css (required): CSS for the theme

themes/
  +- <theme name>/
       |
       +- favicon/
       |    +- <favicon file> (e.g. favicon.ico, favicon.png)
       |
       +- javascripts/
       |    +- theme.js
       |
       +- stylesheets/
            +- application.css
